VORTEX

VORTEX, RZR-63602, RAZOR HD GEN III 6-36X56 FFP EBR-7D MRAD 34mm TUBE

VORTEX, RZR-63602, RAZOR HD GEN III 6-36X56 FFP EBR-7D MRAD 34mm TUBE

Regular price $2,999.99 USD
Regular price Sale price $2,999.99 USD
Sale Sold out
VORTEX RAZOR HD GEN III 6-36X56 FFP EBR-7D MRAD 34mm TUBE

Built around the perfect balance of magnification and field of view, the Razor Gen III 6- 36x56 FFP delivers the resolution and contrast you need for long-range, tactical shooting. To get the absolute most out of the first focal plane reticle, the EBR-7D presents a clean sight picture while still providing ample wind holds and ranging information. Round it out with a rugged build and you have the long-range, tactical solution you've been waiting for.

FEATURES

  • First Focal Plane Reticle - Scale of the EBR-7D reticle remains in proportion to the zoomed image. Constant subtensions allow for accurate holdovers and ranging at all magnifications while the EBR-7D reticle is useful for long-range shooting.<
  • L-Tec+ Zero System - The L-Tec+ Zero System is easy to use with all captive parts and only one set screw, making zeroing quick and simple. Once set, it also allows for more travel
  • HD Optical System - Optimized with select glass elements to deliver exceptional resolution, cut chromatic aberration and provide outstanding color fidelity, edge-to-edge sharpness and light transmission.
  • Micro Adjust Zero Setting - Infinite zero setting positions allow zero to be set between clicks for optimal accuracy.
  • External Rotation Indicator - Provides quick visual and tactile reference of elevation turret's rotational position.
  • XR Plus Fully Multi-Coated - Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
  • Optically Indexed Lenses - Optimize image sharpness and brightness from edge to edge.
  • Plasma Tech - Cutting edge coating application process provides unparalleled coating durability and performance.
  • Glass-Etched Reticle - Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.
  • Aircraft-Grade Aluminum - Constructed from a solid block of aircraft-grade aluminum for strength and rigidity.
  • ArmorTek - Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
  • Hard Anodized - Stealth Shadow Finish Highly durable hard-coat anodization provides a low-glare matte surface and helps camouflage the shooter's position.
  • Locking Side Illumination - Easily accessible and lockable illumination dial is located on the left side of turret housing. Features eleven intensity levels of illumination with off positions between each setting.
  • Waterproof - O-ring seals prevent moisture, dust and debris from penetrating for reliable performance in all environments.
  • Shockproof - Rugged construction withstands recoil and impact.
  • Fogproof - Argon gas purging prevents internal fogging over a wide range of temperatures.



SPECIFICATIONS

  • Magnification - 6-36x
  • Objective Lens Diameter - 56 mm
  • Eye Relief - 3.5 inches
  • Field of View - 20.5-3.5 ft @ 100 yds
  • Tube Size - 34 mm
  • Turret Style - Exposed Locking
  • Adjustment Graduation - .1 MRAD
  • Travel Per Rotation - 10 MRAD
  • Max Elevation Adjustment - 36.1 MRAD
  • Max Windage Adjustment - 15.5 MRAD
  • Parallax Setting - 10 yds to infinity
  • Length - 15.3 inches
  • Weight - 45.1 oz


WHATS IN THE BOX

  • 3 Inch Sunshade
  • Throw Lever
  • Lens Cloth
  • CR2032 Battery
  • Custom 2mm Throw Lever Tool
  • 2.5mm Turret Tool
RETICLE

EBR-7D (MRAD) - Packed with useful subtension data for long-range shooting, the EBR-7D is a hashmarked, ranging reticle available in the first focal plane. A windage tree in the lower two quadrants is perfect for fast follow-up corrections for both wind and elevation. The cross-plex illumination allows for better usability at lower magnification.
