AGM, TAIPAN-TM15-384, TAIPAN THERMAL MONOCULARS

The AGM Taipan thermal monoculars have become synonymous with two words: Reliability and Simplicity. The Taipan TM15-384 is a great mid-level thermal monocular for anyone wanting to experience the capabilities of thermal imaging. Equipped with a highly advanced 12 micron 384x288 resolution thermal sensor and a 1280x960 LCOS display, it’s a great tool for hunters, campers and general outdoors enthusiasts who want or need to detect the presence of other animals or people in complete darkness. The range of uses include blood-tracking for hunters which aids in game retrieval, enhancing safety and awareness for hikers and camp sites and general nighttime curiosity. The Taipan TM15-384 still comes equipped with many of the most popular software features that experienced thermal users have come desire: up to 7.5 hours of battery life from an internal rechargeable battery, Wi-Fi hotspot, AGM Connect app compatibility for exporting and sharing images and videos, 1.5-12X magnification, 8GB of internal storage with no need for a memory card and a 5 Year Transferable Warranty.

• Distance Measurement - The device realizes distance measurement function after marking the top and bottom of target, and input the target height.
• Hot Spot Mark - The device detects and marks the hot spot of highest temperature.
• Mode Switch - Device supports pallet switch and distance measurement.
• Storage - Built-in memory module supports video recording/snapshot capturing.
• Digital Zoom - Device supports 1×, 2×, 4×, and 8× digital zoom.
• Wi-Fi Hotspot - Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

• 384×288 resolution, 12 μm, high sensitivity detector
• Adaptive AGC, DDE, 3D DNR
• 1280 × 960 resolution 0.4-inch LCOS display
• Built-in rechargeable Lithium battery
• More than 7.5 hours continuous running (with Wi-Fi hotspot function off)
• Wi-Fi hotspot
• Type-C interface
• 5-Year warranty

• Interface - USB Type-C
• Pixel Interval - 12 μm
• Multi Language menu - Yes
• Drop Test Height - 1.5 m (4.9 feet)
• Magnification - 1.5x - 12x
• Detector type - Vanadium Oxide Uncooled Focal Plane Arrays
• Response Waveband - 8μm to 14μm
• FFC (Flat Field Correction) - Auto, Manual, External Correction
• Highest Temperature Spot Tracking - Yes
• Standby Mode - Yes
• Refresh rate - 50 Hz
• Aperture - F1.0
• Resolution - 384×288
• Detection Range (6' object) - 710m/yd
• NETD - Less than 35 mk (@25°C), F#=1.0
• Lens (focal length) - 15 mm
• Power - 5 VDC/2 A, 1.5 W
• Field of view (H × X) - 17.5° × 13.1°
• Digital zoom - 2×, 4×, 8×
• Monitor - 1280×960, 0.4 inch, LCOS
• Imaging palettes - Black Hot, White Hot, Red Hot, Fusion
• Storage - Built-in memory module (8 GB)
• Record Video - On-board video recording
• Capture Snapshot - Yes
• Battery Type - Built-in rechargeable Lithium battery
• Wi-Fi - Yes
• CVBS Output - Yes (via USB)
• Battery Operating Time - More than 7.5 hours continuous running (with Wi-Fi hotspot function off)
• Battery Capacity Display - Yes
• Weight - 290 g (0.64 lb)
• Working Temperature/ Humidity - -20°C to 55°C (-4°F to 131°F)
• Overall Dimensions - 158 × 61 × 57 mm (6.23 × 2.4 × 2.2 in)
• Protection Level - IP67

• USB Cable
• Lanyard
• EU Plug
• Lens Cloth
• Operation Manual
