TRIJICON, IRMO-300K, IR PATROL - RIFLE MOUNT KIT

The IR-PATROL has advanced ability to process images with brilliantly sharp detail, and a user-friendly, icon-based menu system for intuitive navigation.Whether your mission is searching for a suspect or securing your position, the Trijicon IR-PATROL is the ideal multipurpose thermal imaging monocular. It's compact, lightweight, rugged and offers some of the most advanced performance options on the market.

• High Detail Imagery: advanced ability to process images with brilliantly sharp detail combined with user-friendly, icon-based menu system for intuitive navigation.
• Fully ruggedized, weatherproof, multidirectional thumbstick control is large and easy to find in complete darkness.
• Edge Detect Tactical Mode projects a fraction of the brightness of other modes to protect against night blindness caused by light from the screen.
• Maxpol Polarity easy to control polarity mode lets you switch between 3 levels of white hot and 3 levels of black hot displays.
• Clip-On Mode Weapon Mount: Wilcox flip mount allows fast attachment and detachment to any Picatinny rail.
• Uncooled VOx (Vanadium Oxide) Sensor Type
• Thermal Sensitivity <50mk
• Monochrome Digital OLED Display Type
• Digital Contrast Enhancement
• Video Output Analog RS-170 (with Optional Cable)
• Start Up Time Approximately 5 Seconds
• Storage Temperature Range -45 to +75 C
• Full 640x480 thermal imager.
• 12 micron pixel pitch.
• Manual user focus control.
• 30 Hz and 60 Hz frame rates.
• GASIR objective lens.
• Tested to MIL-STD-810G methods and procedures.
• 6061 Aircraft-grade aluminum package.
• Waterproof to 1 meter.
• Nitrogen filled.
• Intuitive menu system.
• Included eye guard.
• Handheld or rifle-mounted use.

• Length - 5.95 in
• Width - 2 in
• Height - 2.95 in
• Weight - 16 oz.
• Magnification - 1x
• Day Reticle Color - Black / White Adaptive
• Night Reticle Color - Black / White Adaptive
• Illumination Source - LED
• Power Source - 1 CR123 Battery
• Battery Life - Aprox. 2 hours per battery
• Eye Relief - 1.06 in.
• Field of View (degrees) - 22°
• Mount - Wilcox Shoe Interface, Flip Mount,
• Diopter Range - -6 / +2
• Finish - Matte Black
• Operating Temperature - -40F to +131F
• Sensor Type - Uncooled Vox (Vanadium Oxide)
• Digital Zoom - 8X
• Sensor Resolution - 640x480
• Sensor Pixel Pitch - 12 µm
• Focal Length - 19mm
• Frame Rate - 30 Hz / 60 Hz
• Video Output - Analog RS-170 (with Optional Cable)
• Objective Lens Diameter - 19 mm

• User Manual
• Quick Reference Guide
• 1 CR123 Battery
• Trijicon Logo Sticker
• Protective Eye Cup
• Flip Mount
• Download Card & Cable
• Warranty Card
• Lens Pen
• Hard Case
