RIX, AURORA-A6R, THERMAL IMAGING BINOCULARS

THERMAL IMAGING BINOCULARS

Handheld large-screen thermal imager AURORA A6R, designed for mainstream hunting users, focusing on observation comfort.

• 3D DISPLAY MAP
• High-resolution image quality - High-quality image, equipped with high-end detectors and 35mm F1.0 infrared lens, providing high-definition observation experience.
• Handheld large-screen thermal imager - 2.69-inch large-size OLED display screen in combination with 2.5× eyepieces for binocular observation, avoiding dizziness caused by long-term use of the existing dual-screen products on the market, thus greatly improving observation comfort.
• Ultra-long battery life - Built-in battery plus 8 replaceable AA batteries enabling continuous operation as long as 24 hours.
• More Comfortable Viewing Experience - Unlike thermal imaging binoculars on the market with two eyepiece displays, the AURORA series is the first large single-screen thermal imaging binocular on the market. With a 2.69-inch display screen and 1.5x eyepiece, users of the AURORA will experience less eye fatigue and exhibit no symptoms of dizziness or nausea for long time-term observation.
• High-Definition & Clearly Visible Target - The AURORA A3 is equipped with a 384×288 resolution sensor and a large aperture f35/F1.0 infrared lens, which has extraordinary clarity and detail. With image enhancement technology, The AURORA A3 always provides users with higher-quality, more detailed and high-contrast images, even during rain or fog.
• Long Detection Distance up to 1800m - A powerful long-distance objective lens combined with a 384x288 @12µm sensitive thermal imaging sensor provides exceptional detection capabilities. A standard 1.8m tall object can be detected up to 1800m away in complete darkness.
• Dual Power Supply System - The AURORA A3 is powered by two types of batteries: one built-in with a high capacity of 3700 mAh, and the other external is 8 AA. The combination of both brings it up to 24 hours, solving battery life anxiety, leading to a worry-free, long-term outdoor observation experience.
• Photo & Audio & Video Playback - Built-in 32G storage can record every wonderful moment, while the well-designed program allows users to playback and watch hunting moments. Moreover, built-in WiFi connects the AURORA A3 to smartphones via the application. This opens a wide range of options including real-time image transmission from the device to the smartphone screen and allows for remote control of digital device functions.

Sensor Specifications

• Type - VOx Uncooled
• Resolution, pixels - 640x512
• Pixel Pitch, µm - 12
• NETD, mk - ＜40
• Frame Rate, Hz - 50

Optical Specifications

• Objective Lens, mm - 50mm; F1.1
• Optic Zoom, x - 3.4 to 13.6
• Digital Zoom, x - 1 to 4
• Eye Relief, mm - 30
• Detection Range, m/yd - 2600/2844

Display Specifications

• Type - OLED
• Resolution, pixels - 768×576
• Size, inch - 2.69

Laser Rangefinding

• Safety Requirement - Class 1 (IEC:60825-1)
• Laser Wavelength, nm - 900 to 908
• Measurement Range, m/yd - 5 to 1200m/5.5 to 1312yd
• Measurement Accuracy, m/yd - ±1m/±1.09yd

Wi-Fi

• Wi-Fi / APP - Support (RIX+)

Video Recorder

• Video Recorder - Support
• Memory Capacity, GB - 32

Physical Specifications

• Operating Temperature, °F - -4 to +122
• Weight, lb - 2
• Size, inch - 7.9×5.9×2.4

Connections and Compatibilities

• Built-in Battery - Lithium-ion battery pack 3800mAh / DC3.7V
• External Battery - AA batteries ×8
• Operating Time, h - 8 (only built-in battery) 20 (built-in and external batteries)
• Service Voltage, V - 3V to 4.2V
• External Power Supply, V - 5V (Type-C USB)
